Pedego – Elevate
Original price was: $5,224.00.$2,224.00Current price is: $2,224.00.
Pedego Elevate: Conquer any trail with this full-suspension e-mountain bike featuring the Shimano STEPS EP8 mid-drive motor (85Nm torque) and 36V 14Ah battery for up to 42 miles of range. The 150mm RockShox Revelation fork and 151mm four-bar Horst link rear suspension with RockShox Super Deluxe shock smooth rough terrain. Shimano XT 12-speed drivetrain (10-51T cassette), 4-piston XT hydraulic brakes with 203mm rotors, and Maxxis 29″ x 2.6″ tires with EXO+ protection deliver trail-ready confidence. Includes SDG dropper seatpost, Crank Brothers pedals, and E-TUBE Project compatibility.
Description
Pedego Elevate: Mountain Mastery with Ultimate E-Bike Power
Mountain Mastery with Ultimate E-Bike Power The Pedego Elevate is engineered for serious off-road adventures, combining cutting-edge power and performance with a smooth, responsive ride, making it ideal for conquering rugged terrains and steep trails with ease and confidence.
Key Features & Benefits
- Shimano STEPS EP8 Mid-Drive Motor: 250-watt nominal power with 85Nm max torque output delivers natural, powerful assistance that amplifies your pedaling effort. The compact design features a narrow 177mm Q-factor for optimal pedaling ergonomics.
- Premium 36V Battery System: Darfon 36V 14Ah lithium-ion battery with premium 18650 cells provides up to 42 miles of range, integrated internally in the downtube for sleek aesthetics and protection.
- 3 Levels of Torque Assist: Shimano’s advanced torque sensing technology provides intuitive, natural-feeling power delivery that responds instantly to your pedaling input.
- Full Suspension Confidence: 150mm travel RockShox Revelation RC fork with DebonAir spring plus 151mm travel four-bar Horst link rear suspension with RockShox Super Deluxe Select+ RT shock tackle the roughest trails.
- Precision 12-Speed Drivetrain: Shimano XT M8100 components with 10-51T Hyperglide+ cassette and integrated clutch deliver sharp, reliable shifts across an ultra-wide gear range.
- Powerful 4-Piston Brakes: Shimano XT M8120 hydraulic disc brakes with 203mm rotors provide consistent, reliable stopping power in all conditions. Resin pads offer excellent modulation and low noise.
- Trail-Ready Wheelset: Crank Brothers 29″ rims (31.5mm internal width) with Maxxis Assegai (front) and Minion DHR2 (rear) 2.6″ tires featuring EXO+ sidewall protection deliver exceptional traction and durability.
- Dropper Seatpost: SDG Tellis 30.9mm dropper with up to 125mm of travel allows on-the-fly saddle height adjustment for descending confidence.
- E-TUBE Project Compatible: Connect to Shimano’s proprietary smartphone application to update system firmware and customize motor settings.
Technical Specifications
| Category | Specification | Details |
|---|---|---|
| General Info | Model | Elevate |
| Weight Limit | 250 LB | |
| Ideal Use | Adventure | |
| Speed | 20 MPH | |
| Range | UP TO 42 MILES | |
| Rider Height | 5’4″ to 6’1″+ | |
| Electronics | Motor | SHIMANO STEPS EP8 MID-DRIVE; 250W NOMINAL; 85NM MAX TORQUE; 177MM Q-FACTOR |
| Battery | DARFON 36V 14Ah; PREMIUM 18650 CELLS; INTEGRATED DOWNTUBE MOUNT | |
| Charger | DARFON 5.6 AMP SMART CHARGER; CHARGE INDICATOR LIGHT | |
| Controller | SHIMANO 36V; INTEGRATED INTO DRIVE UNIT | |
| Drivetrain | Rear Derailleur | SHIMANO XT RD-M8100 12-SPEED; INTEGRATED CLUTCH; SGS CAGE |
| Cassette | SHIMANO XT M8100 12-SPEED HYPERGLIDE+ 10-51T; CS-M8100-12 | |
| Shifter | SHIMANO XT M8100 RAPIDFIRE PLUS 12-SPEED; I-SPEC EV; SL-M8100-R | |
| Bottom Bracket | SHIMANO HOLLOWTECH II; 24MM HOLLOW STEEL SPINDLE; INTEGRATED DUAL TORQUE SENSORS | |
| Chain | SHIMANO CN-M8100 12-SPEED | |
| Chain Guide | SHIMANO SM-CDE800 CHAIN DEVICE | |
| Crankset | SHIMANO 3-PIECE; 165MM FORGED ALUMINUM; DIRECT MOUNT 36T CHAINRING | |
| Pedals | CRANK BROTHERS STAMP 1 LARGE; NYLON COMPOSITE; REPLACEABLE STEEL TRACTION PINS; SEALED AXLE | |
| Brakes | Calipers | SHIMANO XT M8120 4-PISTON HYDRAULIC; BR-8120 |
| Levers | SHIMANO XT M8100 HYDRAULIC; SERVOWAVE; BL-M8100 | |
| Pads | SHIMANO N03A-RF RESIN; LOW NOISE; EXCELLENT MODULATION | |
| Rotors | FRONT: SHIMANO DEORE RT64 203MM CENTERLOCK; REAR: SHIMANO DEORE RT-EM600 203MM CENTERLOCK W/ SPEED SENSOR MAGNET | |
| Components | Frame | 6061-T6 ALUMINUM ALLOY; 151MM TRAVEL FOUR BAR HORST LINK REAR SUSPENSION; TAPERED HEAD TUBE; INTERNAL BATTERY & CABLE ROUTING |
| Fork | ROCKSHOX REVELATION RC 29″; 150MM TRAVEL; DEBONAIR SPRING; 35MM STANCHIONS; 15x110MM MAXLE LITE; COMPRESSION & REBOUND ADJUST; HYDRAULIC LOCKOUT | |
| Rear Shock | ROCKSHOX SUPER DELUXE SELECT+ RT; 205MM EYE-TO-EYE; TRUNNION MOUNT; PEDAL COMPRESSION SWITCH; REBOUND ADJUST | |
| Dropper Seatpost | SDG TELLIS 30.9MM; INTEGRATED SADDLE RAIL CLAMP; UP TO 125MM DROP | |
| Saddle | SDG BEL-AIR V3 MAX | |
| Rims | CRANK BROTHERS 29″ 6013-T6 ALLOY; 31.5MM INTERNAL WIDTH; FRONT 28H / REAR 32H | |
| Spokes | FRONT: SAPIM E-LIGHT; REAR: SAPIM STRONG | |
| Grips | SDG THRICE 33MM INTEGRATED LOCK-ON GRIPS | |
| Handlebar | FSA COMET OS35; ALUMINUM ALLOY; 25MM RISE; 760MM WIDTH; 35.0MM CLAMP | |
| Stem | FSA COMET OS35; 50MM LENGTH; 0° RISE; 35.0MM CLAMP; 1 1/8″ THREADLESS | |
| Tires | FRONT: MAXXIS ASSEGAI 29″ x 2.6″ 3C MAXX TERRA, EXO+, TUBELESS READY; REAR: MAXXIS MINION DHR2 29″ x 2.6″ 3C MAXX TERRA, EXO+, TUBELESS READY; PRESTA VALVE | |
| Extras | E-TUBE PROJECT | PROPRIETARY SHIMANO APPLICATION FOR FIRMWARE UPDATES AND SYSTEM CUSTOMIZATION VIA SMARTPHONE/TABLET |
Additional information
| Frame Size | Large, Medium, Small |
|---|
